AS/NZS 1102.104 – Graphical symbols for electrotechnical documentation, Part 104: Basic passive components
Provides symbols for basic passive components such as resistors, capacitors and inductors, ferrite cores, magnetic storage matrices, piezoelectric crystals, electret and delay lines. Based on but not equivalent to and reproduced from IEC 617-4:1996.
Product Details
- Edition:
- 1st
- Published:
- 12/05/1997
- ISBN(s):
- 073371501
- Number of Pages:
- 20
- File Size:
- 1 file , 120 KB
- Product Code(s):
- 10178517, 10178524, 10178505
- Note:
- This product is unavailable in Ukraine, Russia, Belarus
